The Weight-Clarity Paradox Solved
The market deployment of existing AR “Helmet” is hindered by its size, weight and brightness. Realizing monolithic full-color Micro-LED micro-displays is a must for the development of real consumer-level AR glasses.
Highlights
Screen Size
0.13 inch
Micro-LED Density
6350 PPI
Resolution(Color-pixel)
320 x 240
Luminance
500k nits
Gamut Ratio
Parameters
Screen Size
0.13 inch
Micro-LED Density
6350 PPI
Resolution(Color-pixel)
320 x 240
Luminance
500k nits
Chip Size
3.73 mm x 4.13 mm
Active Area
2.62 mm x 1.98 mm
Weight
0.22 g
Pixel Pitch(Sub-pixel)
4.0 μm
Frame Rate
60 Hz
Gray Level
24 bits
Operating Temperature
-20°C~85 °C
Typical Power Consumption
Total: < 200 mW*
*Max Grayscale & Pixel Current (APL:10%)
Wavelength (R/G/B)
630 nm / 535 nm / 465 nm
Contrast Ratio
> 2,000,000: 1
Interface
MIPI & QSPI & SPI
